W.S. Tyler: F-Class Vibrating Screens
W.S. Tyler’s F-Class Vibrating Screens are ideal for challenging screening applications requiring consistent performance and minimal vibration. Featuring an advanced double eccentric shaft design, the four-bearing F-Class ensures the most effective screening action by generating a positive stroke that handles material volume spikes without losing momentum. The dynamically balanced system reduces structural vibration, allowing multiple screens to be placed side by side. The F-Class is available in widths of 4, 6, 8 and 10 ft., and, thanks to its completely modular design, can be run in tandem creating up to a 32-ft.-long screen. Designed for high tonnage outputs, the F-Class can process up to 1,200 tph, providing fast, accurate classification of virtually any material. www.wstyler.ca Photo: W.S. Tyler Keep Reading
Thompson Pump: 8JSCW
Thompson Pump’s 8JSCW high-head, pit dewatering pump is dry-running, portable, automatically priming and diesel-driven. The centrifugal pump offers maximum flows up to 4,250 gpm and high discharge heads up to 660 ft. — ideal for many mining and hydraulic fracking operations that can handle clear liquids or solids up to 2 in. www.ThompsonPump.com Photo: Thompson Pump Keep Reading
Caterpillar: H75Es and H95Es
Caterpillar is expanding the E Series Hammer line with the addition of the new H75Es and H95Es, designed for backhoe loaders and small excavators. E Series Hammers are wholly designed, engineered and manufactured by Caterpillar. The hammers are fully supported by Cat dealers, so customers can work with a single organization for machine and work tool parts and service. E Series hammers feature automatic shutoff, which instantly stops the hammer when the tool breaks through material. The system increases hammer reliability and durability by eliminating the high internal stresses created by blank firing. Sound suppression is standard, for environmental protection and improved operator comfort. www.Cat.com Photo: Caterpillar Keep Reading
KPI-JCI: 9400P
The KPI-JCI 9400P portable fines recovery plant can help aggregate producers reduce the volume of fine material reporting to their settling ponds without the use of flocculants. Key material processing components of the plant include a rubber-lined slurry pump with variable frequency drive, rubber-lined hydrocyclones, a heavy-duty dewatering screen and a dual inlet slurry sump with bypass capabilities, all on a road-portable chassis. To reach maximum capacity, operators can adjust sump, pump, cyclone and screen sizes and quantities. Additionally, an air suspension axle assembly, hydraulic leveling jacks, hydraulically folding cyclone support system and gas/hydraulic power pack ensure ease of plant setup and teardown, without the use of external equipment. www.KPIJCI.com Keep Reading
Wilden: HX400S
Rather than relying on costly external boosters or amplifiers, one of the liquid chambers on Wilden’s new HX400S high-pressure, air-operated double-diaphragm (AODD) pump is used as an amplification chamber. This allows the pump to generate a 2:1 ratio of discharge fluid pressure to air inlet pressure – resulting in the ability to achieve a discharge fluid pressure of up to 250 psig. Additionally, the HX400S pump, which is available with 1.5-in. inlet and discharge connections, is outfitted with Wilden’s Pro-Flo X Air Distribution System. The Pro-Flo X ADS features a state-of-the-art Efficiency Management System, which allows the operator to dial in the actual operational parameters regardless of the application demands or pump size. www.Wildenpump.com Photo: Wilden Keep Reading
Sandvik: CI511/512 crusher
The second generation of compact horizontal impact crushers from Sandvik provides low capital cost solutions, optimum performance and good cubical shape — all while ensuring low operating cost per ton. The all-new patented and highly modularized Sandvik CI511/512 crusher combines the ability to configure one base crusher into either a primary or a secondary configuration. In addition, the crusher is able to produce products with just two curtains for greater breakage. It’s equipped with an infinite hydraulic curtain adjustment, combined with a brake positioning system — relieving pressure and setting when uncrushable objects enter the crusher. No hydraulic power is required during normal operation, thus saving on operating power and reducing total power consumption. www.construction.Sandvik.com Photo: Sandvik Keep Reading
McLanahan: Dewatering screens
Dewatering screens were introduced in the late 1970s by McLanahan and quickly became the standard in the mining industry. McLanahan dewatering screens feature heavy side plates, stress relieved bridges and cross-beams. The cross-beams are Huck-fastened together (not welded) so that individual components can be replaced. Heavy-duty screen media is utilized for all applications and is manufactured in-house by McLanahan’s Polymers Division. This rugged, easily maintained design, along with the versatility of media combinations, is key to superior long-term performance and flexibility. McLanahan dewatering screens offer multiple advantages for construction and specialty aggregate producers including a drier, drip-free product that other types of equipment cannot provide. www.Mclanahan.com Photo: Mclanahan Keep Reading
Griswold Pump Co.: 811 Series (ANSI) centrifugal pumps
Griswold Pump Co.’s 811 Series American National Standards Institute (ANSI) centrifugal pumps are ideal for tank transfer and truck loading and unloading in low-temperature and low-pressure conditions. They have two times the wear area between the case and impeller when compared to closed-impeller designs, the company says. The 811’s open-impeller design also minimizes concentrated wear by balancing the hydraulic thrust load and reducing stuffing-box pressure. The pumps are available in a full range of sizes with flow rates up to 4,000 gpm, with the ability to operate in temperatures up to 500º F. www.GriswoldPump.com Photo: Griswold Pump Keep Reading
Terex MPS: MVP380X
The new Terex Cedarapids MVP380X cone crusher from Terex MPS boasts numerous features that increase the machine’s productivity and ease of use. Major new enhancements include high-speed clearing of jammed material and quick crusher separation capability for faster manganese changes. The new 300-hp MVP380X incorporates pinned cylinder ends that remove quickly to allow fast cone separation, which results in faster manganese changes. At the press of a button, fully guided, dual-action tramp relief cylinders provide 6-in. lift for easy clearing of jammed feed material. The hydro-pneumatic tramp iron relief system instantly resets the crusher setting after passing uncrushable material without having to activate valves and pumps. Rollercone patented super bearing design provides higher efficiency, making more horsepower available for crushing. www.TerexMPS.com Photo: Terex MPS Keep Reading
